Product Details:
|
| Compatible: | 100% Replacement For Original | Delivery: | 3-5 Days |
|---|---|---|---|
| Warranty: | 1 Year | Material: | Cast Iron |
| MOQ: | 1 Piece | Packing: | Wooden Case |
| Keyword: | Slewing Mechaniam | Appliion: | Heavy Machinery |
| High Light: | Wrecker DJ010D hydraulic winch diagram,Wrecker DJ3D hydraulic winch diagram |
||
| Model | W.L.L. 1st layer |
W.L.L. top layer |
Rope Speed |
Rope diam. |
Capacity of Rope |
Working Pressure |
Max Supply Oil Flow |
| kgf | kgf | m/min | mm | m | Mpa | L/min | |
| GW1000 | 1000 | 860 | 30 | 10 | 60 | 16 | 40 |
| GW2000 | 2000 | 1680 | 30 | 12 | 50 | 16 | 70 |
| GW3000 | 3000 | 2526 | 35 | 15 | 65 | 16 | 80 |
| GW4000 | 4000 | 3335 | 35 | 16 | 65 | 17 | 100 |
| GW5000 | 5000 | 4167 | 40 | 20 | 87 | 16 | 160 |
| GW6000 | 6000 | 4922 | 40 | 21.5 | 68 | 16 | 190 |
| GW8000 | 8000 | 6698 | 40 | 24 | 100 | 16 | 260 |
| GW10000 | 10000 | 7846 | 40 | 28 | 90 | 16 | 310 |
| GW12000 | 12000 | 10080 | 30 | 30 | 175 | 17 | 270 |
| GW15000 | 15000 | 9880 | 25 | 34 | 150 | 20 | 240 |
| GW18000 | 18000 | 14700 | 30 | 38 | 143 | 18 | 360 |
products
Elephant Fluid Power is a professional manufacturer and distributorof Hydraulic components which are widely applied to engineer
construction, agriculture, marine, mining, etc. All of the products areof High quality. Including the Hydraulic pump, hydraulic motor, Pumpspare parts,Motor spare parts, Hydraulic Valve, Steering Unit...Elephant Fluid Power Technical team has many years of operationand service experience,Provide customers with professional
hydraulic system solutions,Quality assurance of quality products,We have many years in hydraulic system products,1-7 days, fixedsales engineer, agreement specific delivery period, Years of industryexperience, sales, repairs, commissioning, maintenance, Superfastone-stop professional service, Provide a technical response within2 hours of the standard warranty,Effectively guarantee the quality ofhydraulic products, Worry-free delivery time 1300 kinds in stock,One-stop service, directly with the manufacturer, Provide completehydraulic system solutions,Comprehensive guidance to providetechnical services within 1 working day,Rigorous processing andexcellent quality.
