Product Details:
|
| Appliion: | Excavator Maintain REpair | Structure: | Axial Piston Pump |
|---|---|---|---|
| Warranty: | 12 Months | Power: | Hydraulic |
| Lead Time: | 5-7 Days | Service: | Offer Technical Support |
| High Light: | 5423-928 Axial Piston Pump,Concrete Mixer Axial Piston Pump Hydraulic |
||
Product detail:
Drive shafts - a wide variety of options are available to suit every need.
High strength swash plates on variable pumps and motors - resist deflection under high load.
High strength cast iron housings - provide greater noise damping and wall strength.
High flow check valves in pumps - keep the system primed with minimal pressure drop.
Charge pumps on pumps - gerotor type, several displacement options are available to suit the needs of every appliion. All cast iron construction.
Cartridge shaft seal - lends itself to easy serviceability. Mechanical face seal design tolerates high speed and high pressures.
Table of values (theoretical values, without efficiency and tolerances; values rounded)
| Eaton ACA pump | 3923 | 4623 | 5423 | 6423 | 7620 | |
| Displacement | in3/rev | 3.89 | 4.6 | 5.44 | 6.44 | 7.62 |
| cm3/rev | 63,7 | 75,3 | 89,1 | 105,5 | 124,8 | |
| Maximum Shaft Speed* | Rpm @ 18° | 4160 | 4160 | 3720 | 3720 | 2775 |
| Nominal Pressure** | psi | 6000 | 6000 | 6000 | 6000 | 6000 |
| (bar) | (420) | (420) | (420) | (420) | (420) | |
| Peak Pressure*** | psi | 7000 | 7000 | 7000 | 7000 | 7000 |
| (bar) | (480) | (480) | (480) | (480) | (480) | |
| Output Flow | gpm @3500 psi | 67.3 | 79.2 | 84.1 | 99.1 | 87.9 |
| lpm @241 bar | 255 | 300 | 318 | 375 | 333 | |
| Input Torque | lb-in @3500 psi | 2346 | 2786 | 3285 | 3900 | 4552 |
| Nm @241 bar | 265 | 315 | 371 | 441 | 514 | |
The Eaton Pump we supply the followings models:
| 3923-002 | 3923-003 | 3923-210 | 3923-215 |
| 3923-352 | 3923-355 | 3923-371 | 4623-002 |
| 4623-003 | 4623-007 | 4623-115 | 4623-231 |
| 4623-396 | 4623-432 | 4623-472 | 4623-503 |
| 4623-552 | 4623-553 | 4623-608 | 4623-609 |
| 4623-636 | 4623-654 | 4623-657 | 4623-036 |
| 4623-655 | 4623-654 | 4663-036 | 5423-016 |
| 5423-518 | 5423-715 | 5423-867 | 5423-402 |
| 5423-417 | 5423-297 | 5423-402 | 5423-493 |
| 5423-854 | 5423-867 | 5423-041 | 5423-888 |
| 5423-889 | 5423-297 | 6423-005 | 6423-020 |
| 6423-034 | 6423-071 | 6423-073 | 6423-081 |
| 6423-279 | 6423-405 | 6423-418 | 6423-449 |
| 6423-454 | 6423-511 | 6423-512 | 6423-533 |
| 6423-563 | 6423-577 | 6423-578 | 6423-586 |
| 7620-039 | 7620-316 | 7620-339 | 7620-371 |
| 7620-001 | 7620-010 | 7620-019 | 7620-021 |
| 7620-058 | 7620-094 | 7620-130 | 7620-334 |
Elephant Fluid Power Co.,LtD is an integrated enterprise which focus on all kinds of Hydraulic Piston Pumps and Motors spare parts Supplier. We possess the strength to both sell and supply a wide variety of Construction Machinery Spare Parts we have stable supply channels and familiar with this market.
Often we are able to offer more comprehensive & cost-effective products so can save you time and money. Because of the good quality and highest standard of service, our products have already sell to all over the world, meanwhile we also gained many valuable relationships.
Our Main Business Scope:
1. Hydraulic Pump/Motor Assy & Spare Parts.
2.JCB Pumps
3.Concrete pumps and mixers parts(pumps,motors and gearbox)
4.Oribital motors
5.valvues and steering units
Pls feel free to give us your specific style number if you are interested in our hydraulic series. We will bring you the best product and service at most competitive rate. Sincerely hope to build up the close business relation with you on basis of the mutual benefit in a long term. Thank you
Contact Person: Mr. Han
Fax: 86-311-6812-3061
