Product Details:
|
| Meterial: | Cast,Ductile Iron, Steel, Bronze And Others | Name: | Hydraulic Pump Spare Parts |
|---|---|---|---|
| Type: | MS(E)02,MS(E)05,MS(E)08,MS(E)11,MS(E)18,MS25,MS35,MS50,MS83,MS125... | Appliion: | Piston Pump Repair |
| Quality: | High Quality | Advantage: | Fast Delivery,Advantage Price |
| High Light: | Construction Machinery Hydraulic Piston Pump Parts,Construction Machinery Poclain Hydraulic Motor,Poclain Ms08 Hydraulic Motor |
||
Elephant fluid power company supply the series hydraulic motors, like MS(E)08 Series piston motors
MS(E)08 Hydraulic Motor Appliions:
Mining Machinery: Coal Mine Drill, Heavy Duty Handling Car.
Engineering Machinery: Scavenging Machine, Aircraft Tractor, Beam Carrier/Hoisting Machine.
Farming Machinery: Mini Farming Vehicle, Ditcher
|
Code
|
HMS08
|
|||||
|
Displacement Group
|
6
|
8
|
9
|
0
|
1
|
2
|
|
Displacement(ml/r)
|
467
|
627
|
702
|
780
|
857
|
934
|
|
Theoretical torque at 10Mpa(N.m)
|
743
|
997
|
1116
|
1240
|
1363
|
1485
|
|
Rated speed(r/min)
|
160
|
160
|
125
|
125
|
100
|
100
|
|
Rated pressure(Mpa)
|
25
|
25
|
25
|
25
|
25
|
25
|
|
Rated torque(N.m)
|
1530
|
2050
|
2300
|
2550
|
2800
|
3050
|
|
Max.pressure(Mpa)
|
31.5
|
31.5
|
31.5
|
31.5
|
31.5
|
31.5
|
|
Max.torque(N.m)
|
1890
|
2500
|
2800
|
3150
|
3450
|
3750
|
|
Speed range(r/min)
|
0-210
|
0-210
|
0-185
|
0-170
|
0-155
|
0-140
|
|
Max.power(kW)
|
Standard displacement is 41kW,variable displacement priority rotation 27kW,no priority is 21kW.
|
|||||
features:
-- High performance rotary group with well-proven spherical control area offering the following advantages, self-centering.
-- Low periph-eral speed
-- High efficient.
-- Long service life robust rolling bearing.
-- Drive shaft will support radial loads.
-- Low noise level.
-- High duty roller bearing for intermettent high pressure operation.
-- For continuous duty hydrostatic are availabe.
-- Excellent starting characteristics.
-- High power density
-- Optional mounting position
