Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor

Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor
Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor

Large Image :  Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor

Product Details:
Place of Origin: China
Brand Name: Elephant Fluid Power
Certification: ISO9001
Model Number: BMK2
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Carton box,Wooden box
Delivery Time: 10-30 Days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 30000 Set/month

Ireland Bmk2 Construction Cast Iron Excavator Hydraulic Motor

Description
Meterial: Cast Iron Name: Hydraulic Motor
Model: BMK Application: Hydraulic Equipment
Warranty: 12-18 Months Displacement (cm3 /rev.): 419
Oiginal: Made In China Price: More Favorable Price
High Light:

ireland bmk2 excavator hydraulic motor

,

excavator hydraulic motor ireland bmk2

,

cast iron excavator hydraulic motor



Hydraulic motors in Ireland BMK2 used in construction excavators

BMK2 new series motor adapt the advanced Geroler gear set designed with disc distribution flow and high pressure. The unit
can be supplied the individual variant in operating multifunction in accordance with requirement of applications.



Application:

Hydraulic motors, also known as oil motors, are mainly used in injection molding machinery, ships, hoists, construction machinery, construction machinery, coal mining machinery, mining machinery, metallurgical machinery, ship machinery, petrochemicals, port machinery, etc.





Characteristic featutres:

High-speed motor gear motor has the advantages of small size, light weight, simple structure, good manufacturability, insensitive to oil pollution, impact resistance and small inertia, etc.





Specifications



Type BMK2
65
BMK2
80
BMK2
100
BMK2
125
BMK2
160
BMK2
200
BMK2
250
BMK2
315
BMK2
400
BMK2
475
Geometric displacement (cm3 /rev.) 65 80 100.9 129.8 156.8 193.4 242.5 304.3 390.8 485
Max.speed(rpm) cont. 835 800 742 576 477 385 308 246 191 153
int. 990 980 924 720 713 577 462 365 287 230
Max.torque
(N•m)
cont. 185 235 295 385 455 540 660 765 775 845
int. 245 345 445 560 570 665 820 885 925 930
Max.pressure
drop(MPa)
cont. 20.5 21 21 21 20.5 20.5 20.5 21 15.5 12
int. 27.5 31 31 31 26 26 26 24 17 14
peak 31 31 31 31 31 31 31 31 20.5 17
Max.flow
(L/min)
cont. 55 65 75 75 75 75 75 75 75 75
int. 65 80 95 95 115 115 115 115 115 115
Weight(kg) 9.2 9.4 9.7 10 10.2 10.5 11 11.5 12 12.4

* Continuous pressure:Max.value of operating motor continuously.
* Intermittent pressure:Max.value of operating motor in 6 seconds per minute .
* Peak pressure:Max.value of operating motor in 0.6 second per minute.





Why choose us?



High efficiency
High starting torque
Robust and compact design
High radial and axial bearing capacity
For applications in both open and closed loop hydraulic systems
Suitable for a wide variety of hydraulics fluids
Smooth running over the entire speed range
Constant operating torque over a wide speed range
Long life under extreme operating conditions
High return pressure without the use of drain line (High pressure shaft seal)



Our company:

Elephant Fluid Power provides hydraulic products for mining excavators, including hydraulic motors, hydraulic pumps and hydraulic accessories. These hydraulic products are highly competitive in the hydraulic markets of Ireland, Britain, Germany and Poland. At present, our hydraulic motors have been widely used in the repair and maintenance of construction machinery, agricultural machinery, mining machinery, etc. in this market; at the same time, we also provide spare parts for major hydraulic brands and are available in the European market (such as Ireland, the United Kingdom and Germany). ) Stands for Han Jiu. Brands of hydraulic motors and hydraulic pumps. Our hydraulic motors have been recognized by local consumers in the European market. At present, we hope to further expand the hydraulic product market in Ireland, Portugal, Spain and other regions, and hope to establish long-term good cooperative relations with distributors and end customers in Ireland and other countries.At present, most popular Brands in Hydraulics are Danfoss, Char Lynn, M+S, HANJIU, each with its own merits, however the reason why more and more clients choose HANJIU is because it has obvious advantages over other brands in terms of delivery, service, quality and profit rate.
